Zoje ZJ0303L Automatic Shuffle Direct Drive Walking Foot Sewing Machine


Direct drive, automatic footlift.

Very smooth running and efficient industrial walking foot machine. Equipped with a no noise servo motor mounted on the machine head, this is the motor type of the future. The perfect machine to do heavier work such as upholstery, bags, canvas work, and other applications.

This walking foot machine can do heavy jobs with its high footlift height to ensure that you can get materials underneath the machine. The larger hook also means that you can use thicker thread to sew the product together. Coupled with a top and bottom feed, this machine reduces material slipping.

Automatic Features

The automatic features greatly help with the production process. This machine features an automatic lockstitch at the start, and finish of each sewing line. Also featuring a trimming mechanism, you would no longer need to trim the thread manually using snips. The presser foot can also be programmed to lift after each sewing line. All the automatic functions are actuated using the foot pedal and can be programmed to turn on or off depending on your sewing style.

Larger Working Space

Breeze through larger work with this machine with the extra 10cm of working space (compared to standard models). This allows you to fit more material underneath the arm space.


  • Automatic Needle Positioning system
  • Energy Saving
  • No Noise
  • LED in the Sewing Area
  • Large Underarm Workspace
  • Large rotary hook (2.5x normal sewing machines)
  • High Footlift height: 8mm on handlift and 16mm using kneelift
  • Automatic lubrication, and equipped with an oil pump to cycle the oil
  • 8mm max. stitch length for decorative sewing
  • Adjustable speed
  • Automatic backtack and thread trimmer


  • PVC & banner sewing
  • Canvas sewing: lorry curtains, boat covers, cushion cover bags and luggage.
  • Quilted Goods, horserugs etc.
  • Soft Leather Products: furniture, purses, bags, etc.
  • Decorative sewing

Included Accessories

  • Oil
  • Bobbins
  • Screwdriver
  • Needles

Technical Specification

Sewing Material Weight Medium to Heavy
Max. stitch length 9 mm
Presser foot lift height 16 mm
Max. sewing speed 2000 s.p.m.
Needle system 135×17 / DPx17
Table dimensions (LxW) 1.2×0.6m (Limited adjustable height)


The machine comes built up with a table, motor, thread stand, and all accessories. Mounted on wheels for better mobility.

The colour of the table and stand may vary and be different to that pictured.


Download Section:



1 year return to base warranty.


Free pickup available
$130 for shipping anywhere within New Zealand.


Additional information


Automatic, + Automatic Footlift
